Buzzer
SMBus Connector
LED Pins
Buzzer
SMBus Connector
LED Pins
2. Attach one Serial ATA data cable to each disk drive. Then attach the other
ends of the cables to the connectors on the FastTrak card (above).
3. Attach the Y-cable power splitters to each of the disk drives.
FastTrak SX4300
Ch1
FASTTRAK SX4300
FastTrak SX8300
FASTTRAK SX8300
7
Step 3: Install the Disk Drives
Ch3
Ch2
Ch1 Ch3
Ch2
Ch5 Ch7
Ch6
Ch4
Ch4
Ch8
