Promise fasttrak sx4300 Kurzanleitung Seite 5

3. Install the FastTrak card into the open slot (above).
4. Fasten the FastTrak card bracket to the system case (above).
5. Attach your system case's 2- or 4-pin LED cable to the LED connector on the
FastTrak card (see the Figures below).
Step 3: Install the Disk Drives
The FastTrak SX-Series RAID Controller card supports only Serial ATA disk
drives. For optimal performance, install disk drives of the same model and
If you wish to include your current bootable Serial ATA drive using
the Windows operating system as part of a bootable Mirrored
(RAID 1) logical drive on your FastTrak card, do NOT connect the
disk drive to the FastTrak yet. You MUST install the Windows
driver software first onto this drive while it is still attached to your
existing disk drive controller.
Step 3: Install the Disk Drives
Important
5
