Promise fasttrak sx4300 Kurzanleitung Seite 6

FastTrak SX4300, SX8300 Quick Start Guide
capacity. The drives' matched performance allows the logical drive to function
better as a single drive.
The table above shows the number of drives required for each RAID level. If you
plan to create a mirror (RAID 1) for protection, you can use two new drives OR
use an existing drive and a new drive. The new drive must be the same size or
larger than the existing drive.
1. Install the disk drives into the disk drive bays of your system.
If you are using SuperSwap Enclosures, the SMBus ID of each disk drive
must match the Channel number.
Level
RAID 0
RAID 1
RAID 5
RAID 10
JBOD
Use of removable disk drive enclosures other than Promise
Technology's SuperSwap is not supported and may result in
performance loss or other undesired results.
Number of Drives
2, 3 or 4
2 only
3 or 4
4 only
any number
Caution
6
