Freedom Par Hex-4 QRG EN
The Freedom Par Hex-4 can be operated with the Chauvet DJ IRC-6. For more
IRC-6 (Infrared
information about the IRC-6, download instructions for the IRC-6 or the Freedom
Remote Control)
Par Hex-4 User Manual from http://www.chauvetlighting.com.
Mounting Before mounting this product, read the Safety Notes. Use at least two mounting
points and one safety per product. Make sure the mounting clamps (such as
CLP-15 clamps from Chauvet) are capable of supporting the weight of the
product. For our Chauvet line of mounting clamps, go to
https://www.chauvetdj.com/products/category/accessories/.
Mounting Clamp
(such as the
CLP-15 clamp from
Threaded Mounting
Chauvet)
Hole
Size M12

Mounting Diagram

Safety Cable
(such as CH-05
from Chauvet)
5
