GRAUPNER PARAT Montageanleitung Seite 20

Parts list - PARAT
Part Description
No.
1 Front support
2 Rear support
3 Connecting piece
4 Hull
5 Fin, 2-part
6 Guard plate
7 Baseplate
8 Lateral brace
9 Front brace
10 Rear brace
11 Forestem
12 Bow bulkhead
13 Centre bulkhead
14 Longitudinal bearer
15 Stern bulkhead
16 Deck support
17 Bow plate
18 Servo plate
19 Mounting rail
20 Reinforcement
21 Console
22 Mounting rail
23 Stern plate
24 Battery support
25 Battery retainer strip
26 Battery retainer strip
27 Clevis
28 Main deck
29 Anchor hawse pipe
30 Bulwark
31 Cable hawse, 2-part
32 Buffer strip
33 Bulwark stanchion
34 Superstructure
35 Frame
36 Cross-piece
37 Longitudinal bearer
38 Wheelhouse bottom section
39 Frame
40 Side cladding
41 Wheelhouse centre section
42 Wheelhouse top section
43 Roof support
44 Door console
45 Door
46 Door handle
47 Hinge
48 Funnel
49 Front panel
50 In-fill piece
51 Baseplate
52 Top plate
53 Rear panel
54 In-fill piece
55 Mast
56 Baseplate
57 Top plate
58 Rear panel
No. Material
off
1 Plywood
1 Plywood
2 Plywood
1 ABS
1 ABS
1 ABS
1 ABS
4 Brass tube
1 Alum. tube
1 Alum. tube
1 Plywood
1 Plywood
1 Plywood
2 Plywood
1 Plywood
1 Plywood
1 Plywood
1 Plywood
1 Spruce
2 Spruce
1 Plywood
1 Spruce
1 Plywood
2 Plywood
2 Spruce
4 Spruce
4 Plated steel
1 ABS
2 Brass tube
1 ABS
7 ABS
1 ABS
29 ABS rod
1 ABS
1 Plywood
2 Spruce
2 + 2 Spruce
1 ABS
1 Plywood
2 ABS
1 ABS
1 ABS
1 Plywood
1 ABS
1 ABS
1 Brass rod
2 Brass rod
1 ABS
1 Plywood
1 Plywood
1 Plywood
1 Plywood
1 Plywood
1 Plywood
1 ABS
1 Plywood
1 Plywood
1 Plywood
Dimensions
in mm
Ready made, machined
Ready made, machined
Ready made, machined
Vac. moulded
Vac. moulded
Vac. moulded
Vac. moulded
4/3.2 Ø x 65
8/7.1 Ø x 100
8/7.1 Ø x 90
Die-cut, 4
Die-cut, 4
Die-cut, 4
Die-cut, 4
Die-cut, 4
Die-cut, 4
Die-cut, 4
Die-cut, 4
160 x 8 x 8
130 x 5 x 5
Die-cut, 4
33 x 8 x 8
4, as plan
170 x 75 x 4.0, sheet
150 x 5 x 5
75 x 5 x 5
Order No. 3548
Vac. moulded
6.0/5.2 Ø x 50
Vac. moulded
Vac. moulded
Vac. moulded
3 Ø, L = 33
Vac. moulded
Die-cut, 4
168 x 6 x 6
140 x 6 x 6 and 85 x 6 x 6
Vac. moulded
Die-cut, 4
Die-cut, 1
Vac. moulded
Vac. moulded
Die-cut, 4
Vac. moulded
Die-cut, 1
1 Ø x 6
1 Ø x 5
Vac. moulded
Die-cut, 4
Die-cut
Die-cut
Die-cut
Die-cut
Die-cut
Vac. moulded
Die-cut, 4
Die-cut
Die-cut
