TO STRETCH THE BELT, USE THE PROGRESSIVE NUMERATION
AND THE DIRECTION ARROWS ON THE BUCKLE
1
Following the arrow (1) insert the extremity of the belt from the
innerside towards the external part of the buckle (between the sewn
stirrupand the moving part) From the external side follow the arrow
and goback to the inner side between the arrows (3 and 4).
3
At this point stretch firmly in the indicated direction, so to let the belt
firmly adhere to the tank.
5
Pull firmly and let the buckle overturn.
7
The fastening is assured. Fix the exceeding belt to the apposite Velcro
cloth.
1
3
1
4
2
Pass through the opening marked by the arrow (3) and let
the belt glide.
4
Keep the belt stretched, follow the arrow (4) and go back to the
external side.
6
The buckle will close with a sharp click, blocking the back-pack on
the tank.
