ASSEMBLY INSTRUCTIONS
COMPONENTS (fig. 1):
C base tube
D vertical pole
E cantilever pole
F umbrella
G winch
H handle
M bag with mounting accessories
BASE ASSEMBLY (fig. 2 - fig. 2a)
Follow the instructions of the provided base.
∆ : CAUTION tighten the base bolts well.
∆ : CAUTION ballast the base with a weight of at least
FRAME ASSEMBLY (fig. 3 - fig.3a - fig. 3b - fig. 3c - fig. 3d – fig. 4)
1. (fig. 3a) insert the cantilever pole (E) into the vertical pole (D) and fix the two parts with the bolts (P).
Before inserting it, make sure that the long side of the pole (E) is facing upwards.
∆
: CAUTION tighten the bolts (P) well.
2. (fig. 3b) slide the vertical pole (D) over the base pole (C).
IMPORTANT: (fig. 4) the vertical pole (D) must be pushed down all the way into the square housing of the
orientation ring (O).
3. (fig. 3c) take the umbrella (F) and slide the umbrella attachment (R) over the cantilever pole (E).
∆
: CAUTION the umbrella attachment (R) must be pushed in all the way onto the cantilever pole (E).
4. (fig.3) pass the rope (Z) over the pulley (S).
5. (fig. 3d) screw in the hand wheel (T) into the threaded hole of the vertical pole (D).
6. Insert the winch slot (G) onto the hand wheel (T). Next insert the winch (G) pin (b) into the hole (b')
of the vertical pole (D) and screw the hand wheel (T) well in.
7. Insert the handle (H) into the appropriate hole of the winch (G).
Your CAPRI is now ready for use.
OPENING THE UMBRELLA (fig. 3 - fig.5 - fig . 5a)
IMPORTANT: Before opening the umbrella remove the tie string and, by pulling the ribs with your hands, slightly
open the umbrella.
To open the umbrella, gently turn the handle (H) of the winch (G) clockwise, taking care not to force
the mechanism.
IMPORTANT: (fig. 5) after having opened the umbrella, connect the short stabilizer (L) to its fitting on the frame
(D), using the locking pin (Q).
IMPORTANT: (fig. 5a) insert the rope (Z') into the cleat (L'). This prevents accidental closing of the umbrella.
Z:\Tecnico 2\ISTRUZIONI PRODOTTI\ISTRUZIONI CAPRI\TESTO\CAPRI 2007 -GB-.doc
HOW TO USE YOUR CAPRI
200 kg
(≈ 440 lbs).
2/3
