- When the snooze function is set to OFF, when the time is up to the alarm, touch the "
does not have this snooze function.
Temperature & Humidity Detection:
- Indoor temperature measuring range: -9.9°C (+14°F) ~ +50°C (+122°F), LL.L °C(°F) will displayed if value
lower than -9.9°C (+14°F), HH.H °C(°F) will displayed if value higher than +50°C (+122°F).
- Outdoor temperature measuring range: 40°C (-40°F) ~ +70°C (+158°F), LL.L °C(°F) will displayed if value
lower than -40°C (-40°F), HH.H °C(°F) will displayed if value higher than +70°C (+158°F).
- Indoor and outdoor humidity measuring range: 20%RH ~ 95%RH, 19%RH will displayed if value lower than
20%RH, 96%RH will displayed if value higher than 95%RH.
Wireless sensor transmission:
- When the Weather Station successfully receives signals from the Wireless Sensor, the temperature and
humidity of the "Outdoor sensor" are displayed on the "Outdoor sensor" column of the weather station.
- The Weather station can connect up to 3 channel wireless sensor registration, the use of multiple wireless
sensor, the wireless sensor channel cannot choose the same channel at the same time (a total of 1, 2, 3
channel can choose)
- Press the " " button can switch the display of different channels of outdoor temperature and humidity,
when displaying the symbol "
- If the Weather Station failed to receive transmission from outdoor sensor ("--" display on the LCD), press
and hold " " button for 3 seconds to receive transmission manually. the "Outdoor sensor" will show an
animation of the RF antenna symbol，the Weather Station will re receive the wireless signal of the outdoor
sensor.
F.Y.I.:
- When the wireless sensor set up different channels, the weather station "OUTDOOR REMOTE" also want to
switch to the same channel. When there is no wireless sensor signal transmission on the channel, "--" will be
displayed in the channel of the weather station.
Displaying temperature/humidity and temperature/humidity trend:
- The current indoor temperature/humidity and the temperature/humidity trend (indoors) are shown in the
LCD display.
- After successfully connecting with the remote sensor, the weather station can display the remote
temperature/humidity and the temperature/humidity trend (remote)
- You may see the following displays:
: The temperature/humidity is rising.
: The temperature/humidity is falling.
No display: The temperature/humidity is remaining constant.
Maximum/Minimum Temperature/Relative Humidity:
- To toggle indoor/outdoor maximum, minimum temperature and humidity data, press the "▼" button:
o Once to show the maximum temperature and humidity values.
o Twice to sow the minimum temperature and humidity values
o Three times to return to the current temperature and humidity levels
- To reset the maximum and minimum temperature and humidity, press and hold down the "▼" button
about 2 seconds. This will reset all minimum and maximum data recorded to the current displayed values.
F.Y.I.:
- If the temperature reading is below ranges, the LL.L will be displayed. If the temperature reading is above
ranges, the HH.H will be displayed.
- If the humidity reading is below ranges, the 19%RH will be displayed. If the humidity reading is above
ranges, the 96%RH will be displayed.
Outdoor Temperature alert setting:
Press and hold down the " " button for 2 seconds until the icon for the Temperature Alert" starts to flash
- The upper limit of the Outdoor temperature alert starts to flash. Use the "▲" and "▼" buttons to set the
required maximum temperature. Press "
- The lower limit of the Outdoor temperature alert starts to flash. Use the "▲" and "▼" buttons to set the
required maximum temperature. Press "
- The upper limit of the indoor temperature alert starts to flash. Use the "▲" and "▼" buttons to set the
required maximum temperature. Press "
", will display the channel every 5 seconds automatically switch a channel
" to confirm your setting.
" to confirm your setting.
" to confirm your setting.
" icon position
