Installation
• Attach the clamp bracket to a suitable surface (e.g. table, work bench).
• Tighten the screw clamp, until the clamp bracket sits properly and cannot be moved anymore.
• Insert the foot of the magnifier lamp into the clamp bracket.
• Position the lamp head as desired and then secure it using the wing screw.
LED Control Panel
a) Item No. 1582586
Control Description
Power ON / OFF
Change colour temperature (cool / warm)
Increase brightness
Decrease brightness
Touch and hold brightness control for continuous adjustment, or tap once to fine
tune.
b) Item No. 1601088
Control Description
Power ON / OFF
Increase brightness
Decrease brightness
Operation
• Connect the power plug to a common household power outlet.
• Flip the lid upwards to open.
• Turn power on.
• Adjust LED lighting. See section "LED Control Panel".
• Turn off the product after use and flip the lid down.
Care and Cleaning
• Disconnect the product from the power supply before cleaning.
• Under no circumstances use aggressive cleanings agents, cleaning alcohol or other chemical
solutions since these can penetrate the housing or impair functionality.
• The product does not require any maintenance, do not disassemble it. Have maintenance or
repair services done by a specialist workshop only.
• Clean the product with a dry, fibre-free cloth.
• Use a lens cleaning cloth for cleaning the lens. Alternatively, use a dry, clean, soft and lint-free
cloth or a dust brush. If necessary, you can moisten the cloth with a little lukewarm water.
• When cleaning the lens with a cleaning agent, make sure not to directly apply the cleaner on
the lens. Always apply the cleaning agent directly to the cloth first.
• When cleaning, do not apply too much force on the lens or housing in order to avoid
scratching.
• The LEDs are built-in and cannot be replaced.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in accordance
with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the
environment.

Technical Data

a) Item No. 1582586
Operating voltage ......................... 220 – 240 V/AC, 50 Hz
Power consumption ...................... 10 W
Illuminant ...................................... 96 x 0.2 W SMD-LED
Service life .................................... 20000 h
Luminous flux ............................... 550 lm
Color temperature ......................... 2700 - 3300 K (warm white) / 6000 - 7000 K (cool white)
Lens size ...................................... Ø 125 mm
Lense material .............................. Glass
Magnification factor ...................... 1.75x
Clamping range ............................ max. 50 mm
Protection type .............................. IP20
Operating / storage conditions ...... -10 to +40 °C, <95 % RH
Arm length .................................... 2 x 400 mm
Dimensions (L x W x H) ................ 1280 x 225 x 40 mm
Weight .......................................... 2.37 kg
b) Item No. 1601088
Operating voltage ......................... 220 – 240 V/AC, 50 Hz
Power consumption ...................... Max. 11 W
Illuminant ...................................... 60 x 0.2 W SMD-LED
Service life .................................... 20000 h
Luminous flux ............................... 650 lm
Color temperature ......................... 6000 - 7000 K (cool white)
Lens size ...................................... Ø 125 mm
Lense material .............................. Glass
Magnification factor ...................... 1.75x
Clamping range ............................ max. 50 mm
Protection type .............................. IP20
Operating / storage conditions ...... -10 to +40 °C, <95 % RH
Arm length .................................... 2 x 400 mm
Dimensions (L x W x H) ................ 1250 x 205 x 25 mm
Weight .......................................... 2.43 kg
