Operating Instructions
LED Magnifier Lamp
Item No. 1582586 / 96pcs SMD LED (10 W)
Item No. 1601088 / 60pcs SMD LED (max. 11 W)
Intended Use
The product is intended for magnifying the view of objects. There are 96 SMD LEDs (Item
No. 1582586)/60 SMD LEDs (Item No. 1601088) located underneath the lens intended for
illuminating objects to be viewed. The product must be installed to a suitable surface (e.g. table,
work bench). Power is supplied via a normal household power outlet.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in
bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged. In
addition, improper use can result in short circuits, fires, electric shocks or other hazards. Read
the instructions carefully and store them in a safe place. Make this product available to third
parties only together with its operating instructions.
This product complies with the statutory national and European requirements.
All company names and product names are trademarks of their respective owners. All rights
reserved.

Delivery Content

• LED magnifier lamp
• Clamp bracket
• Power adaptor
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or
scan the QR code shown. Follow the instructions on the website.
Explanation of Symbols
The symbol with the lightning in the triangle is used if there is a risk to your health,
e.g. due to an electric shock.
The symbol with the exclamation mark in the triangle is used to indicate important
information in these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and advice on operation.

Safety Instructions

Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
a) General information
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the appliance from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Always cover the lens with the hinged lid when not in use. Otherwise there is a risk
of fire during direct sunlight since the lens acts like a burning glass.
• Do not touch the lens with your fingers (especially finger nails) or sharp/pointed
objects.
• Never use the lens to stare directly into bright light sources. There is a risk of eye
damage!
• Attention, LED light:
- Do not look directly into the LED light!
- Do not look into the beam directly or with optical instruments!
• Never point the beam of light at mirrors or other reflective surfaces.
• Never point the beam of light at persons or animals. This can lead to eye or skin
injuries.
• Always try to keep the beam of light out of eye level.
• Do not operate the device unsupervised.
• The mains outlet must be located near to the device and be easily accessible.
• Never pull the mains plug from the socket by pulling at the cable. Always pull it
from the mains socket using the intended grips.
• Unplug the mains plug from the mains socket if you do not use the device for an
extended period of time.
• For safety reasons, always unplug the device in case of a thunderstorm.
• Make sure that the mains cable is not squeezed, bent, damaged by sharp edges
or put under mechanical stress. Avoid excessive thermal stress on the mains
cable from extreme heat or cold. Do not modify the mains cable. Otherwise the
mains cable may be damaged. A damaged mains cable can cause a deadly
electric shock.
• Do not touch the mains cable if it is damaged. First, power down the respective
mains socket (e.g. via the respective circuit breaker) and then carefully pull the
mains plug from the mains socket. Never use the product if the mains cable is
damaged.
• To prevent risks, damaged power cables may only be replaced by the manufacturer,
a professional workshop appointed by the manufacturer, or a similarly qualified
person.
• Never plug in or unplug the mains plug when your hands are wet.
• Never use the product immediately after it has been brought from a cold room
into a warm one. The condensation generated could destroy the product. Allow
the device to reach room temperature before connecting and using it. This may
take several hours.
• Never pour liquids above or near the product. There is a risk of electric shock!
• Attach the clamp bracket to a horizontal, flat, and stable surface only.
• Do not attach any objects (e.g. decorative material) to the product.
• Never mount the product in the vicinity of easily flammable materials (i.e. curtains,
fabrics, etc.). Make sure no object (e.g. curtain) can touch or come near the lamp
head, for example due to a draught. Otherwise there is a risk of fire!
• For installations in industrial facilities, follow the accident prevention regulations
for electrical systems and equipment of the government safety organization or the
corresponding authority for your country.
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.

Operating Elements

1
7
8
9
10
2 3 4
1 Upper swivel arm
2 Swivel arm locking screw
3 LED control panel
4 Self-locking lens cover
5 Lens
6 Handle (Item No. 1582586 only)
7 Lower swivel arm
8 Charging connector 220 – 240 V/AC, 50 Hz
9 Clamp bracket
10 Screw clamp
5 6
