Installation instructions
Incremental Shaft Encoder Type RI 42
Item No. 2 521 251, Edition 3 161105 HOR
Introduction
These installation instructions are provided for the connection and starting
procedure of your shaft encoders.
Safety and Operating Instructions
• The incremental shaft encoders of the type RI 42 model series are quality
products manufactured in accordance with established electrical engineering
standards. The units have been delivered from the factory in perfect confor-
mance to safety regulations.
To maintain this condition and to ensure trouble-free operation, please
observe the technical specifications of this document.
• Installation and mounting may only be performed by an electrotechnical
expert!
• The units may only be operated within the limits specified by the technical data.
• Maximum operating voltages must not be exceeded!
The units are designed complying with VDE 0160, protection class III.
To prevent dangerous structure-borne currents, the equipment has to be run
on safety extra-low voltage (SELV) and must be in an area of equipotential
bonding.
• Application: Industrial processes and control systems.
Overvoltage at the connecting terminals must be limited to the values within
overvoltage category II.
• Please avoid shocks to the housing – especially to the encoder shaft – and
axial or radial overload to the encoder shaft.
• Maximum accuracy and durability of our shaft encoders is only granted
when using suitable couplings.
• The high-quality EMC-specifications are only valid together with standard-
type cables and plugs. When using screened cables, the screen must broadly
be connected with ground on both ends. Likewise, the voltage-supply cables
should entirely be screened. If this is not possible you will have to take
appropriate filtering measures.
• Installation environment and wiring are influential on the encoder's EMC:
Thus the installer must secure EMC of the whole facility (device).
• Transient peaks on the power supply leads are to be limited by the pre-
connected power unit to a maximum of 1000 V.
• In electrostaticly threatened areas please take care for neat ESD-protection
of plug and connecting cable during installation work.
• Specified maximum shaft loads are only given under restrictions:
10
– Full bearing life of 1 x 10 revolutions (typ.) will be reached at 35% of full
rated shaft load
8
– a bearing life of 1 x 10 revolutions (typ.) will be reached at 100% of full
rated shaft load.
• For use in class II circuits only
Dimensioned drawing
Connection diagram
Output
Colour (PVC) RS 422 (T),
RS 422 (R)
white Channel A
white/brown Channel A
green Channel B
green/brown Channel B
yellow Channel N
yellow/brownChannel N
1)
yellow/black Sense GND/Alarm
yellow/red Sense V
CC
red 5 V DC
black GND
1 )
Sense GND for RS 422 (T), Alarm for RS 422 (R)
Push-pull (K, D), Push-pull
Open Collector (S) complementary (I)
Channel A Channel A
Channel A
Channel B Channel B
Channel B
Channel N Channel N
Channel N
Alarm Alarm
Sense V
5/10...30/10...24 VDC 10...30 V DC
GND GND
Technical specifications subject to change without notice.
Page 1/1
Mechanical data
Mounting
Shaft diameter
Absolute max. shaft load
Max. speed
Torque
Protection class housing/ball bearing IP 65/64
Operating temperature
Storage temperature
Vibration performance (IEC 68-2-6)
Shock resistance (IEC 68-2-27)
Connection
Material
Weight
1)
use threads M3 for fastening
2)
no standing water allowed at the shaft entrance or at the ball bearing
Electrical data
General design
Power consumption
Supply voltage U
B
1)
Output circuit
Code letter
Output load [mA]
Output voltage [V]
Pulse rise time [ns]
Max. pulse frequency [kHz]
Reverse polarity protection
Short-circuit protection
Pulse duty factor
Pulse width error
Phase shift
Pulse shape
Alarm output
1)
PP=Push-pull; PPcomp.=Push-pull complementary; RS422=Line driver;
O.C. NPN=Open Collector NPN with internal pull up-resistor (10 kΩ)
2)
not against +U
B
Ordering data (see identification plate)
O Standard
R I 4 2 –
Number of pulses
5 ... 1,024
CC
* only with Output S
** Special types are additionally marked by an ordering code -S. In this case customer specifications are to
be applied.
If you don't know these please call us for the specifications, indicating the encoder ordering code.
Hengstler GmbH
Uhlandstr. 49
D-78554 Aldingen Fax +49(0)7424-89500
1)
round flange
6 mm
radial 30 N (6.5 lbs), axial 15 N (3.3 lbs)
10,000 RPM
≤ 1 Ncm
2)
-10 ... +60 °C (Open Collector: 0 ... +60°C)
–25 ... +85 °C
2
100 m/s (10 ... 2,000 Hz)
2
1,000 m/s (6 ms)
cable axial
flange: aluminium, cap: plastics
75 g approx.
as per DIN VDE 0160, protection class III,
contamination level 2, overvoltage class II
5V/40 mA, 24V/30 mA (10...30 V), 24V/40 mA (10...24V)
5 V DC ±10%
(SELV)
PP PP RS422
K D R, T
±10 ±30 ±30
≥2.5 ≥2.5 ≥2.5
High
≤0.5 ≤0.5 ≤0.5
Low
250 100 100
300 300 300
yes no no
yes 1 1
channel channel
1 : 1
± 25° electrical (RS 422, Push-pull)
± 30° electrical (Open Collector NPN)
90° (distance from Channel A to B is at least
0.45 µs, at 300 kHz)
rectangular
Open Collector, NPN (with U
max. 5 mA, 24 V; with U =10...30 VDC: max. 5 mA, 32 V)
B
Supply voltage Type of flange
A 5 VDC R Round flange
E 10 ... 30 VDC
C* 10 ... 24 VDC
/
0
Protection
Output
K Push-pull short circuit proof
class
D Push-pull 5 V, ± 30 mA
4 IP 64
S Open Collector NPN
T RS 422 + Sense
R RS 422 + Alarm
I Push-pull complementary
Tel. +49(0)7424-89 0
10...30 VDC 10...24 VDC
PP, PPcomp. O.C. NPN
K, I S
±30 ±30
U -3 U -2
B B
≤2 ≤0.4
2000 4000
200 50
yes yes
2)
yes yes
=5 VDC or 10...24 VDC:
B
Shaft
diameter
1 6 mm
**
R · 4 1 A
Type of connection
A Cable axial
