LevelOne WBR-6013 Schnellinstallationsanleitung Seite 4

WLAN button
Figure 3
Label Color
Green
Green
Green
Green
Green Ethernet Connected
The icons appear on the products are for application indication only.
The trademark or intellectual property is belonging to their respective owners.
* Actual Rear Panel and ANTENNA may vary depending on model.
Table1.LED function
On
Ready
The device has a
WAN IP address
from xDSL/Cable
Modem
WLAN Ready
N/A
WPS button
Flash
Waiting for device
ready
Transmit / Receive
Data
Transmit / Receive
Data
Start WPS pairing
within 2 minutes
Transmit / Receive
Data
- 2 –
Off
Power Off
Ethernet
Disconnected(No
WAN IP address
from xDSL/Cable
Modem)
WLAN Off
WPS Idle
Ethernet
Disconnected
