Getting Started

STEP 1: Pull out the screw ring, rotate the screw ring in counter-
clockwise direction to loosen the screw and then pulling
the battery cover.
STEP 2: Install the battery to indicated direction.
Close the battery cover and tighten the screw.
STEP 3: Remove the lens' protection cover which in front of the insert tube.
STEP 4: Press the power button to turn on the 550.5380, the power indicator will light,
and then it can be operated.
When to shutdown, please press the power button again.
Operation
Increase/Decrease light Button
- (Light) increasing/decreasing button's function is to adjust
the brightness of camera.
- Each press can lighten or dim the light source for one level.
- Keep pressing the button can continuously adjust the
brightness until release it.

Zoom-in and Mirror Button

This button is a multi-function key, pressing in different ways,
different functions will be enabled.
Zoom-in
Start-up mode: Press once and then release.
- Pressing this button, the target which is taken by the camera
will be 1.5 times zoom-in display on the screen,
as well as shows „ZOOM" on the screen.
- Pressing this button again; the screen will be back to default
size and shows „NORMAL"
on the screen at the same time.
(Figure.1)
(Figure.3)
(Figure.6)
Zoom
(Figure.8)
(Figure.2)
(Figure.4)
Press
(Figure.5)
(Figure.7)
(Figure.9)
