Mirror Button

Start-up mode: Hold 3 seconds and then release.
Starting mirror feature,
the target will be shown in a mirror way on the screen,
as well as shows „M" at the top right of the screen (Figure.11).
Pressing the button for 3 seconds,
it will turn off mirror function and „M" will disappear,
the target will be shown in default mode.
Specifications
Insert Tube
Diameter:
DOF:
Field of View:
Housing:
Light Source:
Length:
Water Resistance:
Working Temperature:
Console
Dimension:
Power Supply:
Estimated Battery life:
Display Resolution:
Screen Type:
Operating Temperature:
Storage Temperature:
Insert Tube Maintenance
• To avoid danger, please do not put the insert tube into any flammable liquid or gas.
• The insert tube contains a series of small wires that control the optics and electronics of the camera tip.
To ensure long-term reliability, do not bend the insert tube more than 180 degrees,
and always bend the insert tube in as large an arc as possible during usage and storage.
Camera Lens cleaning
• User may clean the camera lens with a cotton swab and small amount of cleaning naphtha.
Cautions for Use
• The 550.5380 is designed for industrial use only. Do not use the system for human or any other biological inspection.
!
• Do not insert the insert tube into any flammable gas or liquid (such as a fuel tank) to avoid dangers.
• Do not use the 550.5380 in a fuel tank or other dangerous environments such as a gasoline or alcohol storage tank.
• Do not use any corrosive liquid for cleaning, such as alcohol.
• Do not try to disassemble the product. This presents a shock hazard and could damage the unit.
• Do not bend the insert tube over 180 degrees during usage or storage.
• Please use only recommended components or accessories. Unapproved accessories and components may cause damage.
• Please do not use the 550.5380 in a medical facility or on an airplane,
as the wireless signal may interfere with other critical equipment nearby.
• Avoid direct exposure to sunlight for long periods of time.
• Store the system in a cool, dry and well-ventilated place.
3
8.5mm
4cm~infinity
Horizontal field angle 46°
Vertical field angle 34°
Diagonal field angle 56°
Steel
6 White LED
1M semi-rigid
Insert tube water resistant
0~55°C
93.5 x 209.5 x 57.5mm
4 Alkaline AA 1.5-volt batteries
8hrs
320 x 240
2.4"
0°C~60°C
-20°C~80°C
(Figure.10-Before „Mirror") (Figure.11-After „Mirror")
