HeatTower quick installation
• Except for the base plate / pedestal, the entire heater is already pre-assem-
bled. This saves an enormous amount of time, so that the heater can quickly
be put into operation.
• Remove the heater and the pedestal from the packaging and remove the
foam protectors which are attached to the heating tube to protect it during
transport. Pull these carefully out.
• Now place the heater on a clean, soft surface on the floor turned 180° with
the top down so that the housing is not scratched. You can now see the four
threaded sleeves on the underside of the device, on which the aluminium
stand is now screwed.
• Place the aluminium plate on the threaded sleeves so that the threaded
sleeves can be seen through the holes in the base plate. Caution: You will
now see the black rubberized underside, which is facing in your direction!
• Now carefully screw the four screws through the base plate into the th-
reads. These must not be jammed so that the thread is not damaged. These
must not be tilted so as not to damage the thread.
• Now place the heater back on the floor in the correct orientation.
• The HeatTower is now fully assembled and ready for use.
9.
Hole for ground anchors
(optionally usable)
