Step 3: Turn counterclockwise to remove the defective lamp from the holder. Then carefully screw in the replacement lamp into the holder. If you feel any resistance
remove the bulb to check why there is resistance. Make sure the contacts are in the correct position. One must be flat in the bottom and one must be straight up (fig 3).
Fig.3
Step 4: Pull up the rubber seal again (fig. 5). Make sure it is not crinkled against the bulb.
Fig. 5
USE
Danger !
Danger of electric shock! Only use the light chain when every socket is fitted with a bulb and the rubber seals are positioned securely. Never
touch open sockets.
Hang the light chain using the attachment hook. Plug the power plug into a wall outlet. The lights will light up.
To turn off the power, disconnect the product from the power supply.

CLEANING AND CARE

Cleaning of the product is limited to the surface. Make sure that moisture does not come into contact with any areas of the terminal connections or mains
•
voltage control parts. Only wipe off the product with a dry, lint-free cloth. Never use solvents or aggressive detergents. Disconnect the device from power and
allow it to cool before cleaning.
Lamps have to be replaced when they are obviously damaged, e. g. due to cracks or deep scratches.
•
TECHNICAL SPECIFICATIONS
Power supply:
Power rating:
Protection grade:
Socket:
Distance between lamps:
Maximum ambient temperature Ta:
Maximum housing temperature Tc (steady state):
Min. distance from flammable surfaces:
Min. distance to lighted object:
Total length:
Weight:
Fig. 4
Fig. 6
PS100W-PS100B- PS100G
230V ~ 50hz
25 W per socket, max. 250 W
IP 44
10 x E-27
85 cm
40°C
115° C
0.5 m
0.5 m
10 m
1.2 kg
PS200W-PS200B- PS200G
230V ~ 50hz
25w per portalampada, max 250w
IP44
20 x E27
92,5 cm
40°C
115°C
0.5m
0.5m
20 m
2.3 kg
