Series
HANDHELD MICROPHONE - UNO G8M
Modulation FM
Frequencies range 1785 - 1800 MHz
Channels 192 (12 x 16 groups)
Type Dynamic
Polarity Cardioid
Frequency response 50Hz – 16.000Hz (±3dB)
Signal-to-noise ratio >95dB
Output power 10mW
Controls ON/OFF
Indicators Multi-function LCD
Power supply 2 AA batteries
Operating time >10h with alkaline batteries
Length 254 mm (10")
Max diameter 52.5 mm (2.06")
Weight 390 g (13.8 oz)
UNO G8 Series
14 User manual |
BELTPACK TRANSMITTER - UNO G8B
Modulation FM
Frequencies range 1785 - 1800 MHz
Channels 192 (12 x 16 groups)
Input Mini-XLR
Frequency response 50Hz – 16.000Hz (±3dB)
T.H.D. <0,8%
Signal-to-noise ratio >95dB
Output power 10mW
Controls Power / Mute, select, Gain (3 levels)
Indicators Multi-function LCD
Power supply 2 AA batteries
Operating time >10h with alkaline batteries
Dimensions (W x H x D) 64 x 90 x 23 mm (2.52" x 3.54" x 0.9")
Weight 85 g (3 oz)
UNO G8 Series
15
| User manual
