HANDHELD TRANSMITTER:
14
1
4
2
5
3
6
7
MICROPHONE HEAD
1
GAIN
2
Use this controller to adjust the microphone sensitivity.
Left decrease, right increase.
Factory settings should give you complete satisfaction.
RF POWER SWITCH
3
H stands for High power signal, L for Low power
signal.
IR PORT
4
Receives the Infra Red frequencies sent by the
receiver in order to synchronize and find the best
transmitting frequency.
BATTERIES RACK
5
Please Insert 2 AA Alkaline batteries (LR6 1,5 V)
POWER/ASC
6
Green light: Power On
Green flash: IR transmission in progress
Red flash: battery low
ON/OFF SWITCH
7
CHANGING BATTERIES
Battery life is about 8 hours. If the Low Battery
indicator glows then change the batteries imme-
diately.
