BELTPACK TRANSMITTER:

ANTENNA
1
ON/MUTE/OFF SWITCH
2
The middle position is the mute position
GAIN
3
Mic: Microphone Use
0: Guitar with passive pickup
-10 dB: Guitar with active pickups
MINI XLR INPUT
4
POWER INDICATOR
5
Battery status indicator
WEARING THE BELTPACK TRANSMITTER
Clip the receiver to a belt. For ultimate results, clip the
receiver onto a belt by pushing the receiver down onto
the belt as far as it goes.
For guitarists, attach the guitar strap "through" the
receiver clip.
CHANGING THE BATTERIES
Expected life for two alkaline batteries is approxima-
tively 8 hours.
When the battery status indicator flashes red the
batteries should be changed immediately as show on
the left side. Please Insert 2 AA Alkaline batteries (LR6
1,5 V)
