POS. COD.
3181000002
1
3180201236
2
3 3180201235
3180201234
4
3180201233
5
6 3180201232
3180201231
7
POS. COD.
8 3180700020
9 3040100072
10 3040100017
3040100031
11
3050500007
12
13 3050500002
3050500003
14
15 3080100007
16 3080100003
3080100004
17
18 3180700021
19 3180500008
20 3180100799
3180100888
21
Specification
155200A6312AAAAA
2SN12×M12810-08-08/M22513-08-
08×3200+04
2SN12×M12810-08-08/M22593-08-
08×3200+04
2SN12×M22513-08-08/M22593-08-
08×415+04
2SN12×M22593-08-08/M22593-08-
08×780V0°+04
2SN12×M22593-08-08/M22593-08-
08×800V270°+04
2SN12×M22593-08-08/M22593-08-
08×900V90°+04
Specification
DBL40-0TW/03
GB/T5783-M12×45-8.8-EP•Zn
GB/T5783-M6×65-8.8-EP•Zn
GB/T5783-M8×65-8.8-EP•Zn
GB/T889.1-M12-8-EP•Zn
GB/T889.1-M6-8-EP•Zn
GB/T889.1-M8-8-EP•Zn
GB/T95-12-EP•Zn
GB/T95-6-EP•Zn
GB/T95-8-EP•Zn
LKF.60（ 1／2G）
Q00211341A-08-08
TL-EGE12R1／2EDOMDCF
TL-ET12XCF
Description
Hydraulic motor
Hose
Hose
Hose
Hose
Hose
Hose
Description
Hydraulic valve
Full-thread hex. bolts
Full-thread hex. bolts
Full-thread hex. bolts
Locknut
Locknut
Locknut
Plain washer
Plain washer
Plain washer
Hydraulic valve
Hollow bolt
Transition joints
Transition joints
Qty
2
1
1
1
1
1
1
Qty
1
4
2
2
4
2
2
4
2
6
1
2
1
1
