Sebson WAL SENSOR M INT Bedienungsanleitung Seite 10

Time setting (switching off delay):
Duty cycle of the standby dimming function:
Function test:
Ensure that the motion detector is not obscured. Ensure that the coverage area is not restricted by items such as
through large furniture. To set the detection range and the daylight test, turn the knobs to the positions shown. The
motion detector is activated after a warm-up phase of approx. 30s. If no further movement takes place in the sensing
area of the sensor, the sensor switches off.
Technical Data:
Operating voltage:
Nominal wattage:
Nominal luminous flux:
Rated color temperature:
Electrical protection:
Protection class:
Ambient temperature:
Humidity:
This product contains a light source of energy efficiency class D.
Possibilities of adjustments:
Detection area:
Sensitivity when switching (with regard to
the ambient brightness):
Time setting (switching off delay):
Duty cycle of the standby dimming function
(reduction by the 15% luminosity):
Information for private households (WEEE):
The Electrical and Electronic Equipment Act (WEEE) contains a large number of requirements for the handling of
electrical and electronic equipment. The most important ones are summarised here.
The duration of the operating time can be set continuously from approx. 10s to 15min.
The timer is restarted if a movement from the sensor is detected before the set time
has elapsed.
Immediately after the set time for the switching-off delay has elapsed, the light
intensity of the luminaire can be reduced to 15%. With this setting control, the switch-
on time of this function can be set in steps from 0s (deactivated) to infinity
(permanently activated).
220-240V AC 50Hz
20W
1550lm
6.000K
IP65
II
-20° - +40°C
<93%
Max.9m (<24°C)/ 140°
<3-2.000LUX
Min. 10s +/- 3s - Max. 15min +/-2min
0s, 2min, 30min, 1h, 5h,
∞
10
