10.3 Assembly and disassembly of the water tank

INSTRUCTIONS FOR SETTING UP THE WATER TANK
1. Hold both sides of the water tank, lift it slightly towards
you and remove it from the door in the direction of the
arrow (see figure).
Notes: The seal of the water valve can come loose when
removing the water tank.
2. If the seal of the water valve came loose when removing
the water tank, reinsert it in the recess of the door.
3. Turn the water valve of the water tank counterclockwise
to release.
4. Loosen the lid of the water tank.
5. After disassembly, clean the water tank and lid in water
solution and dry.
6. Screw the water valve clockwise onto the thread of the
water tank again.
7. Place the lid on the water tank to fit.
8. Replace the water tank in the appliance door.
Page 33 of 48
Setting up and connecting
FIGURE
