Image Intensifier
see separate data sheet 'specification of the image intensifier'
Power and Gating Supply for the Image Intensifier
Phosphor Voltage
MCP Voltage
Photocathode Voltage
Gating Module HVP3X
Optical Coupling (Ultra Speed Tandem Lens)
Collimator Lens
Output Lens
Quantum Efficiency (typ.)
Vignetting
Resolution
Scaling Rates
18mm and VGA sensor
25mm and VGA sensor
25mm and SuperVGA sensor
CCD Data
Sensor Type
Number of Pixels
Pixel Size
Sensor Format
Scan Area
Cooling Type
CCD Temperature
Full Well Capacity
Scan Rate
Readout Noise @12.5 MHz
A/D-Converter
A/D Conversion Factor
Max. Quantum Efficiency
monochrome, @ 520nm
Spectral Response (monochrome)
Average Dark Charge
1)
Extinction Ratio
x) Siehe „Definitions and Measurement Conditions"
©PCO 2004
HSFC-PRO

Systemdaten

7)
6 ... 7kV, internally adjusted, ripple ±15mV
0 ... 900V, externally adjusted, ripple ±15mV
on: -180V, off: +80V
In Ultra Fast Gating mode:
min. pulse width: 5ns, optional 3ns, 1.5ns
max. pulsing frequency: 3.3kHz
In High Rate Gating mode:
min. pulse width: 20ns
max. pulsing frequency: 2MHz
Rodenstock F2.5/105mm
F1.0/33mm or F1.5/46mm
> 22%
< 3%
> 60 lp/mm
1:2.17
1:3
1:2.17
VGA
CCD-Interline Progressive Scan with "lens-on-
chip"
640(H) x 480(V)
9.9µm x 9.9µm
½"
6.3mm x 4.8mm
2-stage peltier cooler with forced air cooling
-15°C
-
35.000 e
12.5 MHz
-
13 ... 14 e
12 Bit @12.5MHz
-
7.5 e /count
≥ 40%
280 ... 1000nm
- .
< 0.1 e /pixel sec
1:2000
8. Anhang
SuperVGA
1280(H) x 1024(V)
6.7µm x 6.7µm
2/3"
8.6mm x 6.9mm
-12°C
-
25.000 e
12.5 MHz
-
7 ... 8 e
-
5 e /count
- .
< 0.1 e /pixel sec
1:2000
