Remote-Control unit
1. POWER: Turn the TV on and off.
2. : Search function.
3. Digital Buttons(0-9, -): Directly select channel with digital buttons.
4. SOURCE: Press to open the input source list.
5. NETFLIX: If network connects, press this key to view NETFLIX directly.
6. Google Play: If network connects, press this key to view Google Play directly.
7. YouTube: If network connects, press this key to view YouTube directly.
8. Prime Video: If network connects, press this key to view Prime Video directly.
9. HOME: Display the HOME page.
10. Arrow button ▲▼◄►: Use to select on-screen menu items and change menu values.
11. MENU: Display the main menu or exit the current menu.
12. OK: Confirms selection.
13. BACK: Return to the previous menu.
14. MUTE: Press this button to cut off the sound of the TV set temporarily, press again to
resume.
15. EXIT: Exit the menu.
16. VOL +/- : Press these buttons to adjust the volume.
17. COLOR BUTTONS: It's used in the APPS.
: Open/close in DVD mode.
D.MENU: Quick navigation during Teletext or setup settings / DVD: Video DVD
Menu button.
SETUP: DVD system setup.
D.DISP: Quick navigation during Teletext or setup settings / DVD: DVD Information
button.
18. CH∧/∨: Press these buttons to change channel upward or downward.
19. GUIDE: Select electronic program guide, in DTV mode, it will display all the information
of program in a week when pressing this button.
20. DIGITAL MEDIA PLAYER CONTROL BUTTON: Include backward, forward,
play/pause, stop in USB mode. In DTV mode, press ● button to record the TV program.
Please refer to relevant instructions in the section of multimedia player.
21. LIST: Press to display the channel list.
A-B: Press the A-B button once to set point A. Press the A-B button a second time to set
point B. After setting the program repeat playing from A to B. Pressing the A-B button a third
time will cancel the repeat.
22. TEXT: Press to select the teletext mode.
REPEAT: DVD: Repetition mode button.
23. AUDIO: Press to select mono, nicam, stereo for ATV channel, audio language for DTV
channel.
24. SUBT: Open or close subtitle.
TITLE: Press this button to return to the title of the disc.
8

General Description

Installing Batteries in the Remote Control

Installing Batteries
Open the battery compartment
1
cover on the back side.
Insert two 1.5V AAA size batteries in
2
correct polarity. Don´t mix old or used
batteries with new ones.
3
Closed the cover.
Note:
1) A loading of batteries should be last one year under normal use.
2) If you don't intend to use the remote control for a long period of time, remove batteries to
avoid damage due to leakage.
3) Do not mix old and new batteries or different types.
4) Do not throw batteries into fire or water.
5) The batteries (battery pack or batteries installed) should not be exposed to excessive
heat such as sunshine, fire or the like.
External Connection
Antenna connection
Antenna input impedance of this unit is 75ohm. VHF/UHF 75ohm coaxial cable can be connected to
the antenna jack directly, if the antenna cable is 300ohm parallel flat feeder cable, you need to use
the 300ohm/75ohm converter to connect the antenna cable to the antenna jack.
For details Please refer to the following drawing.
Antennas with 300ohm flat twins Leads
Use a 75ohm - 300ohm converter
ANT IN
300ohm coaxial cable
Antenna feeder
Battery
S l ox
Cover
Point the remote towards the remote
control sensor of the wireless TV and
use it within 7 meters.
Put the used batteries into the recyc-
ling bin since it can negatively affect
2xsize AAA 1.5V
the environment.
Battery
Cover
Antennas with 75ohm Round Leads
75ohm coaxial cable
Antenna cable
