Overview

S l ox
1.SPEAKER
2.REMOTE CONTROL SENSOR
3.POWER INDICATOR
Green: In power on mode.
Red: In standby mode.
4.MENU: Press to see an on-screen menu of your TV's features.
5.SOURCE: Change and select the desired mode.
6.CH+/-: Press to change channels.
In the on-screen menu, use the CH +/- buttons as up/down arrow buttons.
7.VOL+/-: Press to increase or decrease the volume.
In the on-screen menu, use the VOL +/- buttons as left/right arrow buttons
8.POWER: Press this button to turn the TV on or off.
4
7
6
CH+ CH-
5
4
8
DC 12V
Intellinet feeder
1. RJ45
Ethernet connection.
2. COAXIAL OUT
Digital audio output.
3. L/R OUT
Connect to the audio output jacks on your amplifier/home theater.
4. HDMI1/2
Connecting for HDMI signal.
5. DVB-S2
Connected to external SATELLITE to receive.
6. DVB-T2
Connected to external antenna to receive the ATV/DTV program in ATV/DTV mode.
7. USB1/2
USB input.
8. EARPHONE OUT
Connecting for headphone.
9. CI+
Used to insert the CI+ card.
Overview
DVB-S2 & CI+ will not be available in Australia
CI+ will not be available in New Zealand
Digital Audio System
RJ45 COAXIAL L R
HDMI2 HDMI1 DVB-S2
Android OUT OUT
Antenna feeder
Camcorder DVD
Player PC(HDMI-output)
CI+ module
CI+
DVB-T2
USB2 USB2 USB1
EARPHONE
OUT
USB USB
Headset
Blu-ray disc player
