AGST-8800 OUTDOOR WIRELESS WALL SWITCH
EN
1. Open wall switch
Use a flathead screwdriver to remove the button fi rst.
Then place the flat screwdriver in the recess of the frame and lift the screwdriver to unclip the frame from
the back plate. Remove the rubber protector.
2. Pair the wall switch with a receiver
To operate a receiver fi rst you must pair the wireless wall switch with the receiver. Put the receiver in
learning mode (see the manual of the receiver to activate the learning mode).
Give an ON signal on the wall switch when the learning mode of the receiver is active. The receiver will give
a confi rmation that the pairing of the wall switch has been successful.
3. Mount the wall switch
Use a flathead screwdriver to remove the button fi rst.
A
Then place the flat screwdriver in the recess of the frame and lift the screwdriver to unclip the frame from
B
the back plate.
Screw the back plate to a location with a flat surface (make sure the arrow on the back plate points up).
C
After this, fi rst place the rubber protection back on the backplate, then the frame and fi nally the push
button.
4. Operating the wall switch
4a. Dimming
1. Press the ON button to turn on the receiver.
2. Press the ON button again to activate the dimmode. The light will slowly dim in a cycle.
3. Press for the third time the ON button to secure the desired dim level.
4. Press the OFF button to turn off the receiver.
4b. Switching On/Off
1. Press the ON button to turn on the receiver.
2. Press the OFF button to turn off the receiver.
