In the interest of continued product development, Laney reserve the right to amend product specification without prior notice
15
Technical Specifications
Product
Input Impedance (Passive)
Input Impedance (Active)
Output Link Impedance
Output Impedance
Aux Input
Aux Phones
FX SEND
FX RETURN
D.I. Output
Noise Level (20 20KHz Filter) < 50µV
Freq Response Bypassed
Rec Min Load Impd
Power Supply
Typ Current Consumption
Unit dimensions (HWD)
Unit weight
Carton dimensions (HWD)
Packed weight
DB-PRE
BASS PREAMPLIFIER
1MΩ
100KΩ
1KΩ
1KΩ
3.5mm TRS Jack (4.7KΩ Input Impedance)
3.5mm TRS Jack (100Ω Output Impedance)
6.35mm TS Jack -10dBV 1KΩ
6.35mm TS Jack 22KΩ
XLR nominal -20dBV 680Ω
20-20KHz (+/- 0.5dB)
10KΩ
Regulated 9V DC PSU, centre negative,
2.1x5.5x10mm connector type. (Not Included)
90mA
57 x 145 x 122 mm
0.75Kg
93 x 201 x 191 mm
2Kg
DB-PRE
USER MANUAL
