Description
This solid industry capable USB Hub by Delock can be connected to a computer
via the USB Type-A interface. It expands the computer by seven USB Type-A
connectors.
Screw connection and mounting option
Each USB port has two screw holes with M3 thread. Appropriate cables can
be plugged in and screwed into the screw holes. This ensures a secure data
connection even in mobile environments.
In addition, the hub comes with wall mounting plates and a DIN rail bracket,
making it perfect for installation in an industrial environment.
ESD fuse
The USB ports are protected against electrostatic discharges up to 15 kV.
Power supply
If necessary, an optional power supply or an optional power cable can be
connected to the power socket. A voltage between 9 - 36 V can be applied to the
terminal power connection, and 5 V to the DC connection.
Technical details
• Connectors:
1 x USB 2.0 Type-B female
7 x USB 2.0 Type-A female
1 x 5 V DC jack
1 x 9 - 36 V 3 pin terminal power connector
• Chipset: Genesys Logic GL850G
• Data transfer rate up to 480 Mbps
• Bootable
• Plug & Play
• 1 x LED indicator
• Robust metal housing
• USB ports with screw holes
• Pitch of screw hole USB Type-A: ca. 19 mm
• Pitch of screw hole USB Type-B: ca. 19.5 mm
• Thread size: M3
• Removable wall-mount brackets
• Power supply: Bus-powered or Self-powered
• Flexible power supply with 9 V to 36 V at the terminal power connection
• ESD protection up to 15 kV for all ports
