en Basic operation
The clearance between the appliance
and the washing machine must not ex-
ceed 100 cm.
The clearance between the appliance
and the floor must be at least 12 cm and
at most 100 cm.
Do not trap the power cord or the hoses
between the wall and the appliance.
Connecting the water inlet hose
Connect the water outlet hose of the
washing machine to the water inflow on
the rear of the appliance
and secure it using a hose clamp.
If an elbow is attached to the water outlet
hose, remove it.
Connecting the water outlet hose
1. Connect the supplied water outlet hose
to the water outlet on the rear of the ap-
pliance
Fig.
1
a hose clamp.
2. Attach the water outlet hose to the si-
phon, wash basin or plastic pipe with
rubber sleeve.
Water outlet connection types
Secure the water outlet hose against un-
intentional loosening.
Before operating the appliance, ensure
that the wastewater drains away quickly
and eliminate any blockages.
Notes
The draining height must not exceed
100 cm above the floor.
To avoid a significant increase in the pro-
gramme duration, the water outlet hose
must not sag by more than 10 cm. Use
the supplied installation accessories for
securing.
Fig.
3
Siphon
Fig.
4
Secure the connection point with a (24–40
mm) hose clamp.
Sink
Fig.
5
Fix and secure the water outlet hose with an
elbow.
Plastic pipe with rubber sleeve
Fig.
6
8
Fig.
1
/
/
and secure it using
Fix and secure the water outlet hose with an
elbow.
Connecting the appliance to the electri-
city supply
1. Attach the mains plug to the power sup-
ply unit by inserting it and turning it
clockwise.
Fig.
7
2. Connect the appliance plug for the
power supply unit to the mains connec-
tion on the rear of the appliance
Fig.
/
1
.
3. Insert the power supply into a socket
close to the appliance.
4. Check that the power supply is firmly
seated.
Basic operation
operation
Basic
After connection, the appliance is in
standby mode. As soon as a washing pro-
gramme begins, the appliance switches on
automatically.
Note: The consumption values and pro-
gramme duration of the washing machine
may vary depending on the appliance.
Status light
Fig.
The status light
formation about the appliance status and
faults.
Status light
Green light.
Green flashing.
Red flashing during
operation.
Red light.
Red flashing after
emptying the filter
container.
Alternating red and
green flashing.
/
1
provides in-
Information
The appliance is
ready to use.
The appliance is in
operation.
The filter container is
almost full.
The filter container is
full and must be
emptied.
The filter container
has not been inser-
ted fully.
A cleaning pro-
gramme must be
started.
