STEP 1
PREP THE ROBOT
..........
Side Brush
• Remove protective film from robot and dock.
• Attach side brush.
*side brush design may vary
STEP 3
CHARGING YOUR ROBOT
6
h
First
Charge
• Place robot on base to charge for 6 hours.
• Make sure the robot is properly aligned on the base.
• TO TURN ON ROBOT: Place robot on base or press
and hold the CLEAN
button for 5 to 7 seconds
until the indicator lights turn on.
CAN'T CONNECT TO WI-FI?
Restart your phone
• Turn off phone, wait a few minutes, then turn it back on
and connect to Wi-Fi.
Reboot your robot
• Take robot off dock and press and hold down the
CLEAN button on the robot for 12 seconds. Turn your
robot back on by placing it on the dock.
Reboot your router
• Unplug the router power cable for 30 seconds, then
plug it back in. Allow several minutes for your router to
reboot completely.
sha rkcl e a n.eu
SETUP
STEP 2
SET UP THE SELF-EMPTY BASE
0.3m
0.3m
0.6m
• Find a permanent location for the base in a central
area with a strong Wi-Fi signal.
• Remove any objects that are closer than 1m. from either
side of the base, or closer than 1.5m. from the front.
• Plug in the base.
STEP 4
DOWNLOAD THE APP
SharkClean
App Features
Precision Home Mapping
✔
Room Select
✔
Spot Cleaning
✔
Carpet Zones
✔
No Go Zones
✔
Scheduling
✔
MatrixClean
✔
Search "SharkClean" in the app store or scan the QR
code on the front cover to download the app.
Questions? Steps if You're Stuck:
Having trouble connecting to your robot?
For how-to videos, FAQs, troubleshooting, and tips &
tricks visit: sharkclean.eu.
For full instruction booklet visit: qr.sharkclean.com/
qr.sharkclean.com/RV2620EU or
SCAN HERE USING YOUR SMARTPHONE CAMERA
• To use the app, your phone must be
connected to a 2.4 GHz network. The app
will not work on a 5 GHz network.
• DO NOT use a VPN or a proxy server.
• Make sure Wi-Fi isolation is turned off on the router.
Your robot will need to complete an Explore Run
without the mopping Module attached to create a
map of your home.
In the Explore Run, your robot will wander around
your home as it creates a map.
After this run, you can create Carpet Zones in the
areas of your home that you want to the robot to
avoid while mopping. If you do not want to set up
Carpet Zones, or do not have carpets or rugs in your
Place base
home, you can skip this step.
on bare
Now you're ready to clean.
floor against
the wall.
ATTACH MOPPING PAD TO PAD PLATE
• Insert the flat edge of the pad through the
slot in the pad plate
ATTACH PAD PLATE TO ROBOT
• Attach the pad plate
into place on the
underside of the
robot dust bin (you
will hear a click
when properly
attached).
• Insert the robot dust
bin into the robot.
• Your robot is ready to
simultaneously
vacuum and mop your
hard floors.
BEFORE YOU CLEAN
INTERACTIVE MAP WITH CARPET ZONES
HOW TO SET UP MOPPING MODE
Attach the pad plate to your robot to enter Mopping Mode.
In this mode, your robot will vacuum and mop simultaneously.
• Remove the dust bin from the robot. Open the
water reservoir by pulling up on the BLUE gasket.
Fill the water tank with water. Close the water tank
by reinserting the BLUE gasket.
EMPTY WATER RESERVOIR AFTER USE
• For best dry cleaning performance, empty the
water reservoir after use and remove the pad plate.
FILL WATER RESERVOIR
s ha r kc lea n.eu
