Model
Suitable for Hot Tub
（Rectangular ）
Material
Color
Maximum Load
When unpacking this product, check to make sure the parts listed below
are included and carefully inspect for any damage that may have occurred
during transit. If any part is missing or damaged, do not attempt to
assemble or use the product.
NO PICTURE
1
3
5
7
9
11
PRODUCT PAREMETERS
Circular Bead：150＜R＜300mm（6"＜R＜11.8"）
PART LIST
PART NAME QTY
φ27 Left
1
Elbow
φ32 Straight
1
Tubes A
Hook 1
Right Base 1
Screw Cap 18+4
Mechanical
14+2
Wires 5X20
SCL-06
Length：1900-2500mm（74.8-98.4"）
Width：1750-2450mm（69-96.5"）
Aluminum
25kg / 55lbs
NO PICTURE
2
4
6
8
10
12
- 3 -
Black
PART NAME
φ27 Right
Elbow
φ32 Straight
Tubes B
Left Base
Fixed Base
Mechanical
Wires 5X30
Sleeve
QTY
1
2
1
2
20+2
4
