Parts Reference Overview
Before assembling the drain pump, become familiar with all parts.
(See Fig.1)
P6005
Hose Seal Ring
NOTE: To order spare parts for the drain pump, list the part No.
Pump Installation and Operation
1. Connect the provided hose to the drain pump
by fastening the hose clamp. (See Fig.2)
NOTE: Two types of hose adaptors are
provided to be used with different garden
hoses, see Fig.3 & Fig.4 for assembly.
2. Vertically place the drain pump into the pool with
the other end of hose to the drain area.(Check
local regulations for drainage by-laws)
NOTE: Do not put the plug into the pool.
3. To turn on the pump, insert the plug into a
proper socket.
NOTE: When the water level of the pool is
less than 2cm, do not use the drain pump.
NOTE: Keep the drain pump vertical at all
times.
NOTE: Do not dry run the pump.
Pump Maintenance and Storage
CAUTION: YOU MUST ENSURE THE DRAIN
PUMP IS UNPLUGGED BEFORE
PERFORMING MAINTENANCE OR SEVERE
RISK OF INJURY OR DEATH EXISTS.
1. Unplug the pump.
2. Loosen the hose clamps, and remove the hose
from the drain pump.
3. Dry the pump with a cloth and store in a dry
location out of reach from children.
DISPOSAL
Electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.
P6124
Hose Clamp
4
P6556 P6555
Hose Adaptor
Fig.1
P6556
P6124
P6005
Fig.2
P6556
P6124
Fig.3
American
garden hose
P6555
Fig.4
European
garden hose
P6H565
P6555
P6H565
Hose Adaptor
P6H565
P6555
