Connecting the safety edge to the transmitter

Connection examples
IMPORTANT:
The position of the selector
must correspond to the type
of safety edge connected.
IN 2 only supports 8k2
resistive safety devices and
mechanical / contact
devices. The selector 3 is not
applicable if nothing is con-
nected to IN2.
