Adjustment of the receiver / Operating modes

↑
↓
Interference detector
↑
7 s
SW1
265
↓
ms
Operating mode with optical safety edges
↑
ON
SW2
↓
WORK
With resistive or mechanical safety edges, the selector does not work because it is
not necessary to activate the sensors.
R3 function
Low
↑
battery
SW3
↓
Alarm
ON
Any change in the configuration of the switches needs a
reprogramming of the system (see "Programming").
OFF
The equipment is switched to safety state after 7s.
The equipment is switched to safety state after 265ms.
In ON mode, only "always on" optical safety edges (OSE-
S7502B and OSE-S7502) are permitted, as the optical element
always is on.
In WORK mode, the optical elements are OFF meanwhile the
ATEST signal is active. So it is necessary to disconnect this
ATEST signal during the door movement.
In low battery indication mode, the relay contact is closed
when any of the transmitters has an insufficient level of bat-
tery.
In ALARM mode, the relay contact is closed to indicate that
any of the safety edges stored in the receiver are active.
