6. When the battery power on receivers is very
low, the LED will ash red light every 2 seconds.
Please change the batteries.
Turning the TCU and receiver on/o
1. To turn on the Phottix Odin TCU: Press and
hold the Power Button until an image appears
on the LCD screen.
To turn o : Press and hold the Power Button
until the LCD screen goes blank.
2. To turn on the Phottix Odin receiver: Move
the power switch to the "ON" position.
To turn o the receiver by moving the power
switch to the "OFF" position.
En
Groups and Channels
1. The Phottix Odin System has 3 groups: A, B,
and C, and 4 transmission channels: 1, 2, 3, 4.
2. Receivers can be assigned both group and
channel designations.
3. The TCU will allow EV, Power Level and Zoom
setting adjustments to be set for each group of
receivers set to same channel (if the group is
not disabled on the TCU)
The TCU
Connecting to the camera hot shoe
1. Turn o the camera.
2. Slide the Odin TCU into the camera's hot
shoe mount.
INSTRUCTION MANUAL
7
