1. SB910 (in TTL mode) mounted on Nikon
D800: 8 photos can be taken in 2 sec.
2. SB910 (in TTL mode) with Phottix Odin for
Nikon Receiver and Nikon D800 using the
Phottix Odin TCU: 6 photos can be taken in 2
sec.
The Phottix Odin Receiver
Setting Groups on the receiver
1. The Phottix Odin receiver has three group
settings.
2. Move the Group Selection Switch to A, B or C
to select a group for each receiver.
Setting Channels on the receiver
1. The Phottix Odin receiver has 4 channels.
2. Move the Channel Selection Switch to 1, 2, 3,
En
or 4 to select a channel.
3. Ensure the Phottix Odin TCU and receivers
are set to the same channel.
Connecting a ash to the Odin
receiver hot shoe
1. Turn o the ash and the Phottix Odin
Receiver.
2. Slide the ash into the receiver's hot shoe
mount.
3. Lock the ash with the ash's locking
mechanism.
4. Turn on the ash and the Phottix Odin
receiver.
