Sigma HT114 Bedienungsanleitung

Part list
No. Part Qty No.
2
1 2
Pedestal
1
5 6
Transmission rod
Installation instruction
5
7
4
8
6
3
1
STEP2
Install Supporting
F beam(4)
x4
A
1
4x4 5x5
Loosen the 4 screws on the beam (4) with a 4 x 4 wrench (A ),
and then pull the beam apart
Technical data
Column Number
Maximum Load
Maximum speed
Lowest Position
Highest Position
Desktop Size
Applicable Temperature
Part Qty No. Part
1
3
Column
2
7
Supporting plate
STEP1
E
x8
2
A
5x5
Loosen
A
2
70KG
6mm/Round
710mm
1210mm
1200 x 600mm
0~40°C
Qty No. Part
1
4
Column Supporting beam
1
8
Crank
Install Pedestal(1)
A
E
1
3
Install (1) & (2)(3) together, use 5*5 wrench(A) to tighten the screws(E).
2
4
Stretch
Accessory list
Attention: The drawings below are only for reference which might be
slightly different from the actual object, please in kind prevail. Any
tools missing or installation problems, please contact the customer
service firstly.
A
4x4 5x5 2.5x2.5
C D
x4 x14
M6
ST4.2
F G
x4
Nut wrench
M8
Qty No. Part
1
9
2
Baffle
A
F
4
3
Fix the beam to the column (2) (3) as shown
in the figure, and tighten the screw (F) with
a 5 x 5 wrench (A)
HT114
B
x4 x4
M4
E
x8
M6
H
x1 x1
Crank holder
Qty
1
2
2
