Swing topaz Montageanleitung Seite 13

Functions and operation of the wall controller
OFF position- Position 1-
Fan off High fan speed
Setting fan direction for summer and winter
Your ceiling fan can operate in either summer or winter mode.
Summer mode - The reverse switch should be in the SUMMER position to make the fan rotate in a clockwise direction. The
airflow will be directed downwards, for cooling in summer.
Winter mode - The reverse switch should be in the WINTER position to make the fan rotate in a counter clockwise direction.
The airflow will be directed upwards assisting in the circulation of warm air, for energy conservation in winter.
Reverse
Winter
switch
Summer
Position 2- Position 3-
Medium fan speed Low fan speed
Summer
Downwards airflow
Clockwise rotation
Toggle switch –
Light On/Off
Fan speed rotary switch
Light toggle switch
Winter
Upwards airflow
Counter clockwise rotation
13
