ALIGNING THE SUBFRAME
To align the subframe, screw in the fixing
bolts at the marked spots.
Tighten the pins with a torque of max. 20 Nm
to avoid damaging the threads of the fixing
bolts.
Replace the front bolts of the subframe with
fixing bolts successively and tighten them
with a max. torque of 20 Nm.
The position of the subframe is aligned now.
Successively replace the bolts on the bearing
support with fixing bolts and tighten these
with a max. torque of 20 Nm.
