Technical Support and E-Warranty Certificate www.vevor.com/support HEAVY DUTY GARAGE SHELVES USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
Seite 3
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
Seite 4
Warning - To reduce the risk of injury, user must read instructions manual carefully. This symbol, placed before a safety comment, indicates a kind of precaution, warning, or danger. Ignoring this warning may lead to an accident. To reduce the risk of injury, fire, or electrocution, please always follow the recommendations shown below.
Seite 5
5.Do not exceed the listed load bearing capacity. Tighten all the knobs securely before placing weights on it. Be aware of the dynamic load bearing capacity! Sudden load changes may temporarily cause excessive load, resulting in product failure. SAVE THESE INSTRUCTIONS Model 326G0P9FV0 3676V4VPV0 Product size 16×32×62.8inch 16×36×71.4inch Total load limit...
Seite 6
Part Qty 326G0P9FV0 3676V4VPV0 Description Picture Part 16×32×62.8inch 16×36×71.4inch 7mm MDF Upright post Top shelf short beam Top shelf long beam Fixings Post cap Expansion Plug Washer Philips Screws Height of separated 31.4inch 35.7inch shelves - 4 -...
Seite 7
Top shelf beam rivets has a design that allowing MDF to sit. Attention: For additional information regarding the parts listed below, please refer to the Assembly Diagram in this manual. Unwrap and separate all parts in a clear work area. Step 1: Post Cap Assembly 1.
Seite 8
Step 2: Short and Long Beam Assembly 1. Align short beams (C) & top shelf long beam (D) to aligned notches between four upright posts (B). 2. Once in position, tap firmly using a rubber mallet. 3. Repeat process for opposite side, ensuring both ends are set at the same height.
Seite 9
Step 4:Install The Upright Post The bottom of the upright post(B) is secured to each fixing(E), and tap down to the end. Step 5:Install the third, fourth and fifth top shelf long beam(D) and short beam(C); the installation method is the same as Step 2 - 7 -...
Seite 10
Step 6:7mm MDF Top Shelf Assembly 1.Insert 7mm MDF top shelf (A) onto the top shelf supports. 2. Ensure it sits flush with the top of the unit frame. Step7:Install The Top Glue Foot 1. Slide each post (B) into post cap (F) as shown. 2.
Seite 11
Attention: this product can be separated with two shelf. You can find the height of each shelf in the table of part list. Tools Required (not included) Step8-1:Install the anti-tipping screws A:Installation on Solid Concrete Walls 1. Measure and mark off the height & width located for drill hole. - 9 -...
Seite 12
2. Drill 2 holes as marked by power drill. 3. Insert the Plastic Plug with hammer. 4. Attach the shelf to wall, using each 2 pcs,of screw and washer by screwdriver. - 10 -...
Seite 13
Step8-2:Install the anti-tipping screws B:Installation on Wooden Wall Post 1.Measure and mark off the height & width located for drill hole. 2. Drill 2 holes as marked by power drill. 3. Insert the Plastic Plug with hammer. 4. Attach the shelf to wall, using each 2 pcs,of screw and washer by screwdriver.
Seite 14
Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN. Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 E-CrossStu GmbH Mainzer Landstr.69, 60329 Frankfurt am Main. YH CONSULTING LIMITED.
