Product Overview
A
Robot (Top View)
A1
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
Power Indicator Light
• Steady white: Waiting for orders/
Paused/WiFi connected/Cleaning/
Docking/Mapping/Emptying
• Breathing white: Starting up/
Charging (battery level ＞ 20%)
• Flashing white slowly: Waiting for
WiFi connection
• Flashing white quickly: Updating/
Connecting
• Steady red: Battery level ＜ 20%
• Breathing red: Charging (battery
level ＜ 20%)
• Flashing red: Error
Dock
• Press to start docking
Note: Press any button to pause a running robot.
A1-1—LiDAR Sensor
A1-2—Bumper
A1-3—Dock Locator
A1-4—Charging Contacts
Robot (Bottom View)
A2
A2-1—Side Brush
A2-2—Cliff Sensors
A2-3—Omnidirectional Wheel
A2-4—Main Brush Cover Latches
A2-5—Main Brush
A2-6—Main Wheels
A2-7—Mop Module
Dustbin and Water Tank
A3
Combo Unit
A3-1—Water Tank
A3-2—Water Tank Stopper
A3-3—Release Buttons
A3-4—Washable Filter
A3-5—Dustbin
A3-6—Filling Port
A3-7—Filter Holder
A3-8—Filter Holder Latches
Mop Module
A4
A4-1—Mop Cloth Mount
A4-2—Mop Cloth Mount Latches
A4-3—Mop Cloth
A4-4—Hook and Loop Pads
Moisture-Proof Mat
A5
A5-1—Moisture-Proof Mat Adhesive Tape
Power Cord
A6
005
Auto-Empty Dock
A7
A7-1—Dock Cover
A7-2—Dustbin
A7-3—Status Indicator Light
• Steady white: Powered on while the
robot is not docked
• Flashing white slowly: Emptying
• Steady red: Dust bag is not in place
• Off: Powered off or the robot is
charging
Auto-Empty Dock (Top Cover
A8
Open)
A8-1—Disposable Dust Bag
A8-2—Charging Contacts
A8-3—Dock Location Beacon
A8-4—Suction Inlet
Auto-Empty Dock (Back View)
A9
A9-1—Power Port
A9-2—Power Cord Storage Slot
A9-3—Cord Outlets
Note: Power cord can exit at either side.
