English
Layout
Slot 1
POW
ACC
XD
Slot 1
Compact Flash /
Micro Drive
Slot 2
Secure Digital /
Multi Media Card
Slot 3
xD
Slot 4
Micro SD
Slot 5
Memory Stick
*Adapter is required
USB 2.0
CF/MD
Slot 3
CF I, CF II, CF4.0, CF Ultra, CF Ultra DMA, CF Ultra II,
CF Ultra III, CF Ultra IV, CF Extreme, CF Extreme III,
CF Extreme IV, Microdrive, MagicStor
SD, SD Pro, SD Ultra, SD High Capacity (SDHC), Turbo-SD,
SDHC Turbo, SD Ultra, SD Ultra II, SDHC Ultra, SDXC,
SDXC Ultra, MMC-I, MMC-II, MMC plus, MMC plus Turbo,
MMC 4.0, Mini SD*, Mini SDHC*, Turbo Mini SD*, MMCmobile*,
RS-MMC*, RS-MMC 4.0*
xD, xD type M, xD type H
Micro SD, Micro SDHC, Micro SDHC Ultra, T-Flash, MMCmicro
MS Micro, MS-Pro Micro, MS-HG Micro, MS XC-HG Micro, M2
1 5V DUAL
3 USBD_T2-
5 USBD_T2+
7 GND
9 -
Slot 2
MICRO-SD
Slot 4
-2-
SD / MMC
MS/PRO/DUO
Slot 5 USB 2.0 Port
2 5V DUAL
4 USBD_T3-
6 USBD_T3+
8 GND
10 Key
USB2.0
