Befestigung
Fixation
Fissaggio
Fijación
Connection
Montage des Schlauchstop's
Montage du stop
Montagio del stop
Montaje del stop
Installation of limit stop
ø35mm /
1 3/8"
S36
c
700 mm / 27 9/16"
c =
d =
500 mm / 19 11/16"
d
ø35mm /
1 3/8"
S36
Radius min.
= 50mm / 2"
3
