Setting Strap Tension; Setting Soft Tension; Setting Welding Time; Setting Strap Width - Signode BXT2 Bedienerführung

SIGNODE BXT2
1
➟
Fig. 12
1 2
AUTO
➟
MAN.
SOFT
A)
1 2 3 4
900 1100 1300 1500 1700 1900 2100 2300 2500 N
200 247 292 337
B)
1 2 3 4
400 520 640 760
88 116 143 170
Fig. 13
1
➟
Fig. 14
1 2
Fig. 15
20
2 3
=
+ / -
AUTO AUTO
MAN. MAN.
=
SOFT SOFT
3
5 6 7 8
382 427 472 517 560 lbs.
5 6 7 8
880 1000 1120 1240 1500 N
197 224 252 279 335 lbs.
2 3
=
+ / -
3 4

5.6 SETTING STRAP TENSION

– Press the „Function" button (12/1) briefl y.
– Press the „Strap tension" button (12/2) until the
fl ashing digital display (12/3) shows the required strap
tension. Wait two seconds until the new setting is
saved.
1 = min. strap tension approx. 400/900 N*
(88/200 lbs.) (PP)
9 = max. strap tension approx. 1500/2500 N*
(335/560 lbs) (PET)
* refer to Chapter 5.7

5.7 SETTING SOFT TENSION

AUTO
The following two strap tension ranges can
MAN.
be set on the tool:
SOFT A = 900–2500 N (200–560 lbs.)
standard, PET straps
B = 400–1500 N (88–335 lbs.)
Soft tension*, PP straps
* Soft tension: tension wheel starts slowly. Prevents
9
excessive dirt on PP straps.
Setting soft tension:
– Press the „Function" button (13/1) briefl y.
9
– Press the „Mode of operation" button (13/2) several
times until the green „SOFT" LED indicator (13/3)
lights up together with the desired mode of operation
(refer to chapter 5.5).

5.8 SETTING WELDING TIME

– Press the „Function" button (14/1) briefl y.
– Press the „Welding time" button (14/2) until the
fl ashing digital display (14/3) shows the required
welding time. Wait two seconds until the new setting is
saved.
1 = minimum welding time
7 = maximum welding time

5.9 SETTING STRAP WIDTH

The tool can be used with three different strap
widths:
1
– 12–13 mm (
– 15–16 mm ( 5
– 9–11 mm (option)
a) Change strap width from 12–13 mm to 15–16 mm
– Remove battery from tool.
– Release sunk screw (15/2) and remove strap stop
13 mm (15/1).
– Lift the rocker lever towards the handle, release
sunk screw (15/4) and remove strap guide 13 mm
(15/3).
Continuation page 22
/ ")
2
/ ")
8
07.09
