GB | Replacement Wireless Chime & Signal Extender
Use:
A) can be used as a replacement/supplemental chime for button P5760T/
doorchime set P5760, P5763, P5760N, P5763N
or
B) can be used as a signal extender.
For proper usage of the wireless doorchime, read the instruction manual
thoroughly.
Specifications
Transmission range: up to 180 m in an open area (can drop down to one fifth
in a built-up area)
Button: water resistant; enclosure IP44
Pairing of chime with buttons: self-learning function (generation of unique
pairing code)
Pairing capacity: max. 8 buttons per 1 chime
Number of ringtones: 16
Transmission frequency: 433.92 MHz, 10 mW e.r.p. max.
Chime power supply: 3× 1.5 V AA batteries
Button power supply: 1× 3 V battery (type CR2032)
Includes: double-sided adhesive tape, screws
Chime & Signal Extender Description, See Fig. 1
1 – chime LED
2 – speaker
3 – ringing mode button
4 – volume settings button
5 – repeater button (signal repeating)
6 – opening for hanging on a wall
7 – battery compartment
Button Description (Not Included), See Fig. 2
A – battery
B – button for changing ringtone/erasing memory of paired buttons
C – ring button/LED
Opening the Rear Cover of the Button, See Fig. 3
3
