Assembly Instructions
(Please refer to the actual size.）
Step 1
P
Connect the five chair legs to the base using ten M6x12 screws, then insert the wheels.
Step 2
Insert the gas lift into the central hole of the chair base.
Step 3
T
R
E
Use four M6x20 screws and 6mm washers to attach the seat cushion to the mechanism,
ensuring correct orientation.
03
Scan for
Video Guide
A
B
C
I
Front
Step 4
Q
M
Use three M8x40 screws and 8mm washers to connect the backrest to the seat cushion.
Step 5
Align the assembled upper part of the chair with the gas lift and insert it.
Step 6
O
K
S
N
Use two M8x45 screws, spring washers, and 10mm washers to attach the armrests to the
backrest. After tightening the screws, press the two decorative caps into the armrest
screw holes, ensuring correct placement for the left and right sides.
Front
H
04
