User Manual
Parts List
(Please refer to the actual size. Each type of screw and washer has one reserved as a spare.）
Key
Description
A
Wheels
B
Chair leg tubes
C
Base
D
Seat cushion
E
Mechanism
Armrest
F
G
Headrest
H
Backrest
I
Gas lift
J
Left armrest decorative cover
K
Right armrest decorative cover
L
6mm washer
M
8mm washer
Note: Please sort the screws and measure their lengths beforehand for easier assembly.
01
Part
Qty.
Spare
5
5
1
1
1
1 pair
1
1
1
1
1
1
1
4
1
3
1
Key
Description
N
10mm washer
O
Spring washer
P
Chair leg screw (M6x12)
Q
Backrest screw (M8x40)
R
Mechanism screw (M6x20)
S
Armrest screw (M8x45)
T
Hex wrench
Part
Qty.
Spare
2
1
2
1
10
1
3
1
1
4
1
2
1
02
