OWNER'S MANUAL -English
Battery recharge
TS-T2 is equipped for using a 3,7V Li-ion rechargeable battery pack which can be recharged by connecting
the USB cable to the radio and to a USB-charger (5V- 1A). It takes 4 hours to fully recharge the radio.
For maximum battery life, we recommend charging the battery pack when the TS-T2 is off and the battery
pack is fully discharged.
The Battery power saving feature enables a reduction in consumption of up to 50%.
If it has been set, it automatically activates when the transceiver does not receive any signal for more than 5
seconds in order to save the battery life.
The Power saving function is activated by default and can be modified only by software.
Maintenance
Your TS-T2 was designed to fulfill any warranty obligations and to enjoy this product for many years.
As for all the electronically devices, we recommend you to follow this few sugge-stions:
• Do not attempt to open the unit. Non-expert handling of the unit may damage it and/or annul the
warranty. When using regulated power supply, take notice of power voltage, that must be between
3,4V and 4,2V to avoid damages.
• High temperatures can shorten the life of electronic devices, and warp or melt certain plastics. Do not
store the radio in dusty or dirty areas.
• Keep the Radio dry. Rainwater or damp will corrode electronic circuits.
• If it appears that the Radio diffuses peculiar smell or smoke, please shut off its power immediately and
take off the charger or battery from the Radio.
8
Technical Specifications
General Part
Frequency Range
Working temperature
Operation Voltage
Operation Mode
Dimensions
Weight
Antenna Impedance
Duty cycle
Transmitter Part
Frequency Stability
RF Output Power
Max frequency deviation
Audio distortion
Adjacent Channel Power
Spurious radiation
Occupied bandwidth
Receiver Part
Receive Sensitivity
Audio distortion
Audio response
Adjacent Channel Selectivity
Inter modulation rejection
Spurious response
Blocking
NOTE: All specifications may be modified without prior notice or liability.
OWNER'S MANUAL -English
PMR446
-10°C to +40°C
DC 3.7 V ±10%
Simplex
150mm×55mm×32mm (with Antenna)
133g (Battery pack included)
50ohm
5/5/90%
±2.5ppm
≤500mW ERP
≤2.5KHz
≤3%
< 60dB
Within European legal terms
Within European legal terms
< 0.2μV @20dB SINAD
≤3%
300 Hz ~ 3 KHz
Within European legal terms
Within European legal terms
Within European legal terms
Within European legal terms
