Description of remote control
1. Volume control
2. Headset left/right balance
3. Equalizer ( Sound Clarity mode )
How to install Amplicomms TV3500
Connecting the base
1. Connect the power adapter to the DC input socket located on the base rear
panel.
2. Connect the power adapter provided to an electrical outlet.
3. Connect the base to your audio source.
There are 2 ways to connect the base to the audio source (TV/Hifi): either using
one of the two supplied cables (analog or optical), or using TV/Hifi audio sound
(if no audio output socket on your TV/Hifi device). Cable mode is prefered.
Check on your TV / Hifi set which audio output solution is available (analog or
optical).
All manuals and user guides at all-guides.com
1
2
3
Optical cable (3.b)
Analog cable (3.a)
19
