Description of base
Base top view
5
1. Charging cradle
2. Power LED indicator
3. Input LED indicator ( 3 = Microphone, 2 = Analog input, 1 = Optical input/
TOSLINK )
4. Battery low LED indicator
5. Microphone hole
6. Remote control support
Base rear view
7. Power supply socket
8. Analog Audio In Socket (3.5 mm)
9. Optical Audio In Socket TOSLINK
10. 3 = Microphone, 2 = Analog input (3.5mm), 1 = Optical input/TOSLINK Aux
Switch
11. Pairing button
